796-E...

Impact Sockets 1/4"

Details
  • for outside TORX®screws
  • for power tools
  • special steel, phosphated
  • female square according to DIN 3121-G6, 3, ISO 1174
  • TORX®= reg. trademark of Acument Intellectual Properties, LLC. USA
Explanation for the table
Code Number Torx size corner to corner
Length
mm
l1
mm
d1
mm
Weight
g
More add Buy
0796000045000 796-E4 3,86 23 3,2 7,4 15
X

ELORA Code: 0796000045000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de
PU: 6
d2 mm: 13
Locking Pin : 7883-11
Locking Ring : 7884-11
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000055000 796-E5 4,73 23 3,2 8,3 15
X

ELORA Code: 0796000055000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de
PU: 6
d2 mm: 13
Locking Pin : 7883-11
Locking Ring : 7884-11
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000065000 796-E6 5,74 23 4 9,3 15
X

ELORA Code: 0796000065000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de
PU: 6
d2 mm: 13
Locking Pin : 7883-11
Locking Ring : 7884-11
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000075000 796-E7 6,16 23 4,8 9,8 15
X

ELORA Code: 0796000075000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de
PU: 6
d2 mm: 13
Locking Pin : 7883-11
Locking Ring : 7884-11
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000085000 796-E8 7,52 23 5,6 11,1 15
X

ELORA Code: 0796000085000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de
PU: 6
d2 mm: 13
Locking Pin : 7883-11
Locking Ring : 7884-11
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000105000 796-E10 9,42 23 6,4 13 16
X

ELORA Code: 0796000105000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de
PU: 6
d2 mm: 13
Locking Pin : 7883-11
Locking Ring : 7884-11
Productinformation:
Attention:
locking pin and locking ring are not included!
Code Number Buy
0796000045000 796-E4
X

ELORA Code: 0796000045000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de

Details
Torx size corner to corner 3,86
Length mm 23
l1 mm 3,2
d1 mm 7,4
d2 mm 13
Locking Pin 7883-11
Locking Ring 7884-11
Weight g15
PU6
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000055000 796-E5
X

ELORA Code: 0796000055000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de

Details
Torx size corner to corner 4,73
Length mm 23
l1 mm 3,2
d1 mm 8,3
d2 mm 13
Locking Pin 7883-11
Locking Ring 7884-11
Weight g15
PU6
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000065000 796-E6
X

ELORA Code: 0796000065000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de

Details
Torx size corner to corner 5,74
Length mm 23
l1 mm 4
d1 mm 9,3
d2 mm 13
Locking Pin 7883-11
Locking Ring 7884-11
Weight g15
PU6
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000075000 796-E7
X

ELORA Code: 0796000075000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de

Details
Torx size corner to corner 6,16
Length mm 23
l1 mm 4,8
d1 mm 9,8
d2 mm 13
Locking Pin 7883-11
Locking Ring 7884-11
Weight g15
PU6
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000085000 796-E8
X

ELORA Code: 0796000085000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de

Details
Torx size corner to corner 7,52
Length mm 23
l1 mm 5,6
d1 mm 11,1
d2 mm 13
Locking Pin 7883-11
Locking Ring 7884-11
Weight g15
PU6
Productinformation:
Attention:
locking pin and locking ring are not included!
0796000105000 796-E10
X

ELORA Code: 0796000105000

available in the following shops:
Mercateo Deutschland AG
www.mercateo.com
MW PARTS GmbH
www.mwparts.com
Wuppertools Werkzeughandel
www.wuppertools.de

Details
Torx size corner to corner 9,42
Length mm 23
l1 mm 6,4
d1 mm 13
d2 mm 13
Locking Pin 7883-11
Locking Ring 7884-11
Weight g16
PU6
Productinformation:
Attention:
locking pin and locking ring are not included!
