Clicking Torque Wrenches and Insert Tools

Clicking Torque Wrenches and Insert Tools

Torque Wrench with rectangular intake

2033-20
Torque Wrench with rectangular intake

for use with ELORA interchangeable spanner heads
main measurement unit for Nm with vernier scale, secondary measurement unit for ft-lb
safe locking of the set torque value
bi-directional fixing by turning the torque wrench
with robust, matt steel tube
with very noticeable and audible ("click") signal
nonslip QUATROLIT-2C-handle
factory depth gauges: Ss = 17,5 mm (9x12 mm) and Ss = 25 mm (14x18 mm)
according to DIN EN ISO 6789:2017 Part 1, Typ ll Class A
with traceable declaration of conformance
tripping accuracy +- 4%

show more show less

Torque Wrench with rectangular intake

2034-...
Torque Wrench with rectangular intake

for use with ELORA interchangeable spanner heads
main measurement unit for Nm with vernier scale, secondary measurement unit for ft.-lb.
safe locking of the adjusted torque value by securing button at the handle end
ELORA-No. 2179-S: exchanging the locking knob through the safety cap, the torque can be fixed tamper-resistant
for clockwise and anti-clockwise tightening by turning the torque wrench
with robust, matt steel tube
with very noticeable and audible (‚‘click‘‘) signal
nonslip QUATROLIT®-2C-handle
factory depth gauges: Ss = 17,5 mm (9 x 12 mm) and Ss = 25 mm (14 x 18 mm)
according to DIN EN ISO 6789:2017 Part 1, Typ II Class A
with traceable declaration of conformance
tripping accuracy + - 3% (2034-20 + - 4%)

show more show less

Ratchet Insert Tools, fine tooth

2072-..., 2076-1
Ratchet Insert Tools, fine tooth

with small robust head
forged, fine tooth gear wheel with handy metal switching disc
5° smallest swivel angle
with locking pin
chrome vanadium 31CrV3 / 1.2208
male square according to DIN 3120, ISO 1174, with ball locking device

show more show less

Open End Spanner Insert Tool

2052-..., 2056-...
Open End Spanner Insert Tool

attention, changes setting value for ELORA-Nr. 2052-14 -19 and 2056-27 - 41
forged
with locking pin
chrome-plated
chrome vanadium 31CrV3 / 1.2208

show more show less

Fixed Square Insert Tools

2074-..., 2078-1
Fixed Square Insert Tools

forged with locking pin
chrome-plated
chrome vanadium 31CrV3 / 1.2208
male square according to DIN 3120, ISO 1174, with ball locking device

Ring Spanner Insert Tool

2062-..., 2066-...
Ring Spanner Insert Tool

attention, changes setting value for ELORA-Nr. 2066-27 to 41
forged
with locking pin
chrome-plated
chrome vanadium 31CrV3 / 1.2208

show more show less

Open Ring Spanner Insert Tool

2063-...
Open Ring Spanner Insert Tool

forged
with locking pin
chrome-plated
chrome vanadium 31CrV3 / 1.2208

2071-...
Adapter

attention, changes setting value
for use with insert tools 9x12 mm and 14x8 mm
forged
chrome-plated
chrome vanadium 31CrV3 / 1.2208

show more show less

Torque Wrench Set

2034-200 S13M
Torque Wrench Set

13 pcs.
in black plastic case with foamed inlay
