Professional Pneumatic Tools

Professional Pneumatic Tools

Pneumatic Impact Wrench Mini, 1080 Nm

5003N
Pneumatic Impact Wrench Mini, 1080 Nm

extremely handy impact wrench with only 108 mm length
for work at difficult accessible areas
maximum performance at minimum weight
with vibration-damped composite housing
non-slip cold insulated handle
exhaust air guided through handle
always full capacity when loosening
clockwise 3-step torque regulation when tightening
clockwise/counter clockwise performance regulation protected in rear motor plate
with high-performance twin-hammer clutch system
air inlet thread 1/4‘‘
Operating pressure 6,3 bar max. sound level 85 dB (A) Lp A
average air consumption 118 l/min
recommended hose inner-Ø 8 mm
vibration acceleration 4,3 m/s²
including steel nipple
maximum loosening 1080 Nm

show more show less

Pneumatic Impact Wrench Mini, 450 Nm

5004
Pneumatic Impact Wrench Mini, 450 Nm

extremely handy impact wrench with only 160 mm length
for work at difficult accessible areas
maximum performance at minimum weight
with vibration-damped composite housing
non-slip cold insulated handle
exhaust air guided through handle
always full capacity when loosening
clockwise 3-step torque regulation when tightening
clockwise/counter clockwise performance regulation protected in rear motor plate
with high-performance twin-hammer mechanism
air inlet thread 1/4‘‘
Operating pressure 6,3 bar Tightening torque max. 450 Nm
max. sound level 95 dB (A) Lp A
average air consumption 100 l/min
recommended hose inner-Ø 8 mm
vibration acceleration 5,9 m/s²
including brass nipple

show more show less

Pneumatic Impact Wrench 1/2", 1850 Nm

5000N
Pneumatic Impact Wrench 1/2", 1850 Nm

extremely powerful and ultra light
max. torque 1850 Nm at just 2 kg weight
with vibration-damped composite housing
non-slip cold insulated handle
exhaust air guided through handle
always full capacity when loosening
clockwise- 3-step torque regulation when tightening
clockwise/counter clockwise performance regulation protected in rear motor plate
with high-performance twin-hammer clutch system
air inlet thread 1/4‘‘
operating pressure 6,3 bar
Maximum loosening 1850 Nm
max. sound level 85 dB (A) Lp A
average air consumption 161 l/min
recommended hose inner-Ø 8 mm
vibration acceleration 6,5 m/s²
including steel nipple

show more show less

Pneumatic Impact Wrench 3/4", 2340 Nm

5001N
Pneumatic Impact Wrench 3/4", 2340 Nm

extremely powerful and ultra light
max. torque 2340 Nm at just 3,5 kg weight
with vibration-damped composite housing
non-slip cold insulated handle
exhaust air guided through handle
always full capacity when loosening
clockwise- 3-step torque regulation when tightening
clockwise/counter clockwise performance regulation protected in rear motor plate
with high-performance twin-hammer clutch system
air inlet thread 3/8‘‘
operating pressure 6,3 bar
Maximum loosening 2340 Nm
max. sound level 85 dB (A) Lp A
average air consumption 221 l/min
recommended hose inner-Ø 13 mm
vibration acceleration 7,7 m/s²
including steel nipple

show more show less

Pneumatic Impact Wrench 1" with long spindle, 2450 Nm

5002
Pneumatic Impact Wrench 1" with long spindle, 2450 Nm

extremely powerful with optimal working weight
max. torque 2450 Nm at just 7,2 kg weight
with vibration-damped composite housing
non-slip cold insulated handle
swivel air inlet thread and exhaust air guided through handle
always full capacity when loosening
clockwise- 3-step torque regulation when tightening
clockwise/counter clockwise performance regulation protected in rear motor plate
with super high-performance twin-hammer mechanism
air inlet thread 1/2‘‘
operating pressure 6,3 bar
Tightening torque max. 2450 Nm
Maximum loosening 3500 Nm
max. sound level 95 dB (A) Lp A
average air consumption 370 l/min
recommended hose inner-Ø 13 mm
vibration acceleration 52,2 m/s²
including brass nipple

show more show less

Pneumatic Ratchet Wrench 1/4"

5011
Pneumatic Ratchet Wrench 1/4"

for effortless working at difficult accesible areas
very light composite housing
handy design
clockwise/counter-clockwise convertible at ratchet head
non-slip cold insulated handle
exhaust air guided through handle
little vibration only
air inlet thread 1/4‘‘
operating pressure 6,3 bar
Tightening torque max. 35 Nm
free-running speed 220 rpm
max. sound level 72 dB (A) Lp A
average air consumption 100 l/min
recommended hose inner-Ø 8 mm
including brass nipple

show more show less

Pneumatic Ratchet Wrench 90 Nm

5010, 5012
Pneumatic Ratchet Wrench 90 Nm

extremely handy ratchet wrench with only 160 mm length
for effortless working at difficult accessible areas
maximum performance at minimum weight
very light composite housing
handy design
clockwise/counter-clockwise convertible at ratchet head
exhaust air guided through handle
non-slip cold insulated handle
little vibration only
air inlet thread 1/4‘‘
operating pressure 6,3 bar
Tightening torque max. 90 Nm
free-running speed 170 rpm
average air consumption 170 l/min
max. sound level 93 dB (A) Lp A
recommended hose inner-Ø 8 mm
including brass nipple

show more show less

Pneumatic Drills, reversible

5005, 5006
Pneumatic Drills, reversible

robust housing
handy design
direction of rotation reversible
ELORA-No. 5005: drill chuck, clamping capacity up to Ø 13 mm
ELORA-No. 5006: keyless drill-chuck, clamping capacity up to Ø 10 mm
Non-slip cold insulated handle
exhaust air guided through handle
little vibration
air inlet thread 1/4''
operating pressure 6,3 bar
ELORA-No. 5005: max. free-running speed 750 rpm
ELORA-No. 5006: max. free running speed 1800 rpm
max. sound level 87 dB (A) Lp A
average air consumption 240 l/min
recommended hose inner- Ø 8 mm
including brass nipple

show more show less

Grinder straight Ø 6 mm

5014
Grinder straight Ø 6 mm

for grinding, polishing and deburring
robust and light housing
ergonomical designed for easy one-handed operation
low vibration
Speed infinitely adjustable with safety trigger
non-slip, cold- insulated handle
Collet Ø 6 mm
Air-inlet thread 1/4''
Operating pressure 6,3 bar
Max. free-running speed 25000 rpm.
Max. sound level 86 dB(A)Lp A
Average air consumption 270 l/min.
recommended hose inner- Ø 8 mm
including brass nipple

show more show less

Angle Grinder Ø 6 mm

5015
Angle Grinder Ø 6 mm

for grinding, polishing and deburring
robust and light housing
ergonomically designed for easy one-handed operation
low vibration
Speed infinitely adjustable with safety trigger
Non-slip cold- insulated handle
Collet Ø 6 mm
Air-inlet thread 1/4''
Operating pressure 6,3 bar
Max. free-running speed 22000 rpm.
Max. sound level 72 dB(A)Lp A
Average air consumption 270 l/min.
recommended hose inner- Ø 8 mm
including brass nipple

show more show less

Angle Grinder Ø 125 mm

5016
Angle Grinder Ø 125 mm

robust housing
lateral grip for left and right use
release with safety trigger
with spindle lock for disc change
for grinding discs with Ø 125 mm and 6 mm thickness (M14 x 1,5)
Air-inlet thread 1/4''
Operating pressure 6,3 bar
Max. free-running speed 11000 rpm.
Max. sound level 86 dB(A)Lp A
Average air consumption 490 l/min.
recommended hose inner- Ø 8 mm
including brass nipple

show more show less

Angle Grinder Ø 180 mm

5017
Angle Grinder Ø 180 mm

robust housing
lateral grip for left and right use
release with safety trigger
with spindle lock for disc change
for grinding discs with Ø 180 mm and 6 mm thickness (M14 x 2)
Air-inlet thread 3/8''
Operating pressure 6,3 bar
Max. free-running speed 7000 rpm
Max. sound level 86 dB(A)Lp A
Average air consumption 500 l/min.
recommended hose inner- Ø 13 mm
including brass nipple

show more show less

5019
Needle Scaler

for efficient removal of rust or many other coatings
only suitable for solid metal parts, no steel sheets
2-piece housing for easy maintenance
non-slip cold insulated handle
19 (3 mm) needles
Air-inlet thread 1/4''
Operating pressure 6,3 bar
Number of strokes 3700/min.
Max. sound level 108 dB(A)Lp A
Average air consumption 120 l/min.
recommended hose inner- Ø 8 mm
including brass nipple

show more show less

5018
Sabre Saw Set

for metal and body work
Suitable for small radii
robust housing and safety lever
with non-slip cold-insulated handle
exhaust air guided through handle
adjustable bow-wing skid
with 5 sawblades, mini-oiler and swivel connection to prevent kinking of the hose
Air-inlet thread 1/4''
Operating pressure 6,3 bar
Stroke length 10 mm
Cutting capacity 1,5 mm
Number of strokes 9500/min.
Max. sound level 83 dB(A)Lp A
Average air consumption 170 l/min.
recommended hose inner- Ø 8 mm
including brass nipple

show more show less
