Tape Measures, Rulers, Spirit Level, Steel and Dial Indicators

Tape Measures, Rulers, Spirit Level, Steel and Dial Indicators

1544H
Folding Rule

reading 1 mm
according to accuracy class III of the EC regulation
hinges made of epoxy lacquered steel
with hidden rivet
beech wood

show more show less

1546-...
Measuring Tape

according to precision class II
measuring tape corresponds to EU-directive 2014/32/EU, i.e. it is CE-marked and due to this initially calibrated
partitioning 1mm
automatic strip-intake with return stop
with one-sided double scale
gliding end hook, double riveted
with belt clip
curved, kink resistant measuring tape
handy 2 component housing made of high-strength ABS plastic
measuring tape made of 65Mn spring steel, yellow
with nylon coat, ensuring abrasion resistance and anticorrosive coating

show more show less

1546XL-...
Measuring Tape

according to precision class II
measuring tape corresponds to EU-directive 2014/32/EU, i.e. it is CE-marked and due to this initially calibrated
with warp resistant, light A-frame
with tangential tape extraction for protection against deformation of the tape
ergonomic grip design
steal measuring tape, white lacquered and sealed with transparent UV-lacquer
protection against subsurface corrosion by zinc phosphating
one-sided partitioning 1 mm
start A (measure starts approx. 10cm behind the fitting) with plastic ring
roll-up mechanism running on a steel shaft with high plain bearings effect

show more show less

Flexible Steel Rules

1545-...
Flexible Steel Rules

according to accuracy class II of the EC regulation
graduation in mm
stainless spring band steel

Flexible Steel Rules

1547-...
Flexible Steel Rules

according to accuracy class II of the EC regulation
graduation in mm
stainless spring band steel

Aluminium Ruler

1552-...
Aluminium Ruler

graduation in mm
pattern with touching edge and anodized surface
aluminium alloy

Precision Straight-Edge Ruler

1553-...
Precision Straight-Edge Ruler

in case
accuracy class 00
for checking the evenness of surfaces
through hardened, measuring surfaces lapped
handle insulated as isolation against hand warm
high grade tool steel
DIN 874

show more show less

Marking Gauges with Flat Slider

1582-...
Marking Gauges with Flat Slider

for precise measurement by stop on the work piece
graduation in mm
flat pattern with hardened marking edge and locking screw
matt chrome plated
factory norm

show more show less

1554-...
Spirit Levels

accuracy: 0,5 mm/m = 0,029°
with unbreakable vials made of acrylic glass
horizontal vials with magnifying lens
lateral mm graduation
rectangular aluminium profile (50 x 21 mm), surface plastic coated

show more show less

Precision Dial Indicator

1555
Precision Dial Indicator

in plastic storage case
clamping shank 8 mm h7 diameter
adjustable tolerance marks
housing made of stainless steel

Precision Dial Mini Indicator

1557
Precision Dial Mini Indicator

in plastic storage case
clamping shank 8 mm h6
adjustable tolerance marks
housing made of stainless steel

Universal Magnetic Dial Gauge Stand

1565
Universal Magnetic Dial Gauge Stand

for holding dial indicators ELORA-No. 1555 and 1557
on / off switching for activation of the magnetic stand (65 x 50 x 55 mm) with an adhesive force of 600N
Ø 8 mm dial indicator holding hole
vertical bar 230 mm, horizontal bar 200 mm
leverage hard chrome plated with fine adjustment

show more show less
