Brakes, Wheels, Chasis

Brakes, Wheels, Chasis

165-400 PROLOG
Tyre Lever

especially suitable for car tyres
drop forged pattern with profile shaft
matt chrome-plated
Chrome-Vanadium 31 CrV3 / 1.2208

Impact Sockets 1/2"

790LTP...
Impact Sockets 1/2"

for power tools
extra deep with, with plastic sleeve
for wheel mounting, plastic sleeve to protect the rims from scratches
coloured size identification
female square drive according to DIN 3121-H 12,5, ISO 1174
special steel

show more show less

Impact Socket Set 1/2"

790-LTPS3
Impact Socket Set 1/2"

3 pcs., in plastic box
extra deep, plastic sleeve, in plastic box
for wheel mounting, plastic sleeve to protect the rims from scratches
for power tools
coloured size identification
female square drive according to DIN 3121-H 12,5, ISO 1174
special steel

show more show less

Impact Sockets 1/2"

790DW-...
Impact Sockets 1/2"

for power tools
extra deep
suitable appropiate for deep lying bolts
square drive according to DIN 3121-G12,5, ISO1174
special steel, phosphatized

show more show less

Wheel Nut Wrench

170-...
Wheel Nut Wrench

for loosening and tightening of wheel nuts and wheel bolts of trucks
forged pattern
additional 13/16 AF female square drive within the size of 32 mm, for operating of wheel bolts with male square drive
to operate with tommy bar ELORA-No. 171
nickel-plated
special tool steel

show more show less

Tommy Bars for Wheel Nut Wrench

171-...
Tommy Bars for Wheel Nut Wrench

to operate the wheel nut wrench ELORA-No. 170
nickel-plated
Chrome-Vanadium 31CrV3 / 1.2208

Wheel Nut Wrench

185-...
Wheel Nut Wrench

bent pattern with hub cap puller
matt chrome-plated
Chrome-Vanadium 31CrV3 / 1.2208

Four Way Wheel Nut Wrench

195WS-...
Four Way Wheel Nut Wrench

for cars, light trucks and agricultural machinery
silver coated
high grade tool steel
pattern according to DIN 3119, ISO 6788

Four Way Wheel Nut Wrench

195CV-17, 195CV-5/8
Four Way Wheel Nut Wrench

for cars, light trucks and agricultural machinery
heavy-duty pattern
matt chrome-plated
Chrome-Vanadium 31CrV3 / 1.2208
pattern according to DIN 3119, ISO 6788

show more show less

Four Way Wheel Nut Wrench

195CV-...
Four Way Wheel Nut Wrench

for loosening and tightening of wheel nuts and wheel bolts of trucks and tractors
heavy-duty pattern
matt chrome-plated
Chrome-Vanadium 31CrV3 / 1.2208
pattern according to DIN 3119, ISO 6788

show more show less

Four Way Wheel Nut Wrench

196-...
Four Way Wheel Nut Wrench

for loosening and tightening of wheel nuts and bolts of trucks, tractors and construction machinery
heavy-duty pattern due to forged centrepiece
dimensions: 750 x 750 mm
additional 13 / 16” female square within the size 32 mm for operating of wheel nuts with male square
matt chrome-plated
Chrome-Vanadium 31CrV3 / 1.2208
pattern according to DIN 3119, ISO 6788

show more show less

163
Tyre Lever

especially suitable for tubeless tyres
heavy-duty pattern
matt chrome-plated
Chrome-Vanadium 31CrV3 / 1.2208

165-...
Tyre Lever

especially suitable for car tyres
drop forged pattern with profile shaft
matt chrome-plated
Chrome-Vanadium 31 CrV3 / 1.2208

186
Tyre Lever

especially suitable for truck tyres
heavy-duty pattern
matt chrome-plated
Chrome-Vanadium 31CrV3 / 1.2208

Balance Weight Plier

243MB
Balance Weight Plier

for loosening, tightening and cutting of balance weights on rims
for setting retaining springs on balance weights
chrome-plated
Chrome-Vanadium 31CrV3 / 1.2208

Balance Weight Plier

243MB-1
Balance Weight Plier

for loosening, tightening and cutting of balance weights on rims
for setting retaining springs on balance weights
with plastic head on the hammer side, especially for painted weights
chrome-plated
Chrome-Vanadium 31CrV3 / 1.2208

show more show less

Tyre Tread Gauge

198
Tyre Tread Gauge

for measuring the tyre tread
measuring range 0-30 mm
reading accuracy 0,1 mm (vernier scale 1/10 mm)
lenght of locating surface 23 mm
solid brass

show more show less

167-1
Valve Rotator

for screwing on and off the valve inserts as well as for pushing the valve pin in tyre valves
plastic grip

Tyre Pressure Gauge

167
Tyre Pressure Gauge

with cranked measuring intake for VG8 screw thread
with push-button for resetting the indicator and rotatable for zero regulation
measuring scale 0-10 bar, resp. 0-140 PSI
pressure indication in BAR and PSI
accuracy ± 1% of the value

show more show less

Brake Piston Reset Tool

302
Brake Piston Reset Tool

for resetting the pistons in brake disc callipers without screw thread reset adjuster
suitable for all common types of vehicles
nickel-plated, jaws gunmetal-finish
high grade tool steel C45 / 1.0503

File for Brake Service

292
File for Brake Service

for removing braking dust and rust in the brake callipers of car disc brakes
rough milled
2-C-handle
Tool steel 140Cr3/1.2008

File for Brake Service

292-1
File for Brake Service

for removing braking dust and rust in the brake callipers of car disc brakes
4-sides rough milled
2-C-handle
Tool steel 140Cr3/1.2008

Brush for Brake Service

293BS
Brush for Brake Service

for removing braking dust and rust in the brake callipers of car disc brakes
narrow pattern, width 12 mm
bristles made of straight steel wire
2C-handle

Brush for Brake Service

293
Brush for Brake Service

for removing braking dust and rust in the brake callipers of car disc brakes
narrow, bent pattern
plastic handle
bristles made of corrugated steel wire

Brake Spring Plier

480-340
Brake Spring Plier

for removing and replacing of brake shoe return springs in drum brakes
with a moveable claw, especially suitable for glued brake linings
nickel-plated, with black coated handles
Chrome-Vanadium 59CrV4 / 1.2242

329-...
Separators

for removing connecting rods, ball rods, drop arms etc.
massive forged pattern
handle knurled
zinc-plated
high grade tool steel

show more show less

Precison Vernier Caliper for Brake Discs

1523
Precison Vernier Caliper for Brake Discs

1/20 mm (reading of 0,05mm) and 1/128" vernier scale
pattern with trailing vernier and locking screw
vernier matt chromed
stainless steel

Brake Spring Pliers

480-...
Brake Spring Pliers

for removing and replacing of brake shoe return springs in drum brakes
especially suitable for riveted brake linings
nickel-plated
Chrome-Vanadium 59CrV4 / 1.2242

Axial Grip Plier

513
Axial Grip Plier

for clamping of overlapping metal sheets during spot welding, makes it possible to weld 4 clean spots without moving the plier, for use on doorways, side pieces, etc.
slim shape with quick release lever
jaw adjustment: 0-15 mm
jaw wideness: 57 mm
bright nickel-plated, black jaws
jaws made of high-strength steel

show more show less

Axial Grip Plier

516
Axial Grip Plier

for the rectangular clamping of two metal sheet pieces of the same thickness, for welding from fillet straight to the metal sheet edge
slim shape with quick release lever
jaw adjustment: 0-10 mm
jaw wideness: 50 mm
bright nickel-plated, black jaws
jaws made of high-strength steel

show more show less

Axial Grip Plier

517
Axial Grip Plier

for clamping of U-profiles and U-shaped body profiles, especially appropriate for adjusting door sills, wheel housings, roofs and side panels for afterwards spot welding between the plier jaws
slim shape with quick release lever
jaw adjustment: 0-15 mm
jaw wideness: 45 mm
nickel-plated, black jaws
jaws made of high-strength steel

show more show less

Micro Grip Plier

519
Micro Grip Plier

high grade, hardened and tempered aluminium alloy, 120 g light only
ergonomic design with rounded shape
one-hand operation
axial movement of the moveable jaw
brass screw is also the moveable jaw
brass screw/ moveable jaw made of solid brass
knurled knob of the brass adjust screw
anodized body

show more show less

Sockets 1/2", extra deep, metric

771-LT...
Sockets 1/2", extra deep, metric

especially suitable for deep-set female screws on long threaded bolts
hot forged
chrome-plated, polished
knurled
ELORA-Chrome-Vanadium 31CrV3 / 1.2208
female square according to DIN 3120-C 12,5, ISO 1174, with ball retaining groove
according to DIN 3124, ISO 2725-1

show more show less

Sockets 1/2", extra deep, inch

771-LTA...
Sockets 1/2", extra deep, inch

especially suitable for deep-set female screws on long threaded bolts
hot forged
chrome-plated, polished
knurled
ELORA-Chrome-Vanadium 31CrV3 / 1.2208
female square according to DIN 3120-C 12,5, ISO 1174, with ball retaining groove
according to DIN 3124, ISO 2725-1

show more show less
