206-...
Massive Steckschlüssel


Details
- zu betätigen mit Maulschlüssel, Stufendrehstift ELORA-Nr. 212-2 oder ELORA-Nr. 212-3
- aus dem Vollen geschmiedet
- verchromt, Köpfe geschliffen
- Drehstifte sind im Lieferumfang nicht enthalten
- Chrom-Vanadium 31 CrV 3 / 1.2208
- Ausführung nach DIN 896, Form A / ISO 2236/1085
Code | Nummer | Länge mm |
h1 mm |
h2 mm |
sw mm |
Gewicht g |
Mehr | Merken |
---|---|---|---|---|---|---|---|---|
0206006071000 | 206-6x7 | 103 | 10,0 | 11,0 | 7,0 | 30 | ||
0206008091000 | 206-8x9 | 108 | 12,5 | 13,5 | 9,0 | 60 | ||
0206010111000 | 206-10x11 | 120 | 15,0 | 16,0 | 11,0 | 80 | ||
0206012131000 | 206-12x13 | 138 | 17,3 | 18,8 | 13,0 | 125 | ||
0206013171000 | 206-13x17 | 153 | 19,8 | 23,9 | 16,0 | 140 | ||
0206014151000 | 206-14x15 | 145 | 19,8 | 21,1 | 14,0 | 143 | ||
0206016171000 | 206-16x17 | 153 | 22,4 | 23,9 | 16,0 | 150 | ||
0206016181000 | 206-16x18* | 158 | 23,9 | 25,2 | 18,0 | 150 | ||
0206018191000 | 206-18x19 | 163 | 25,2 | 26,2 | 18,0 | 235 | ||
0206018211000 | 206-18x21 | 168 | 26,2 | 28,8 | 20,0 | 235 | ||
0206020221000 | 206-20x22 | 173 | 27,6 | 30,1 | 20,0 | 290 | ||
0206021231000 | 206-21x23 | 183 | 28,8 | 30,8 | 21,0 | 340 | ||
0206024261000 | 206-24x26 | 193 | 32,6 | 34,6 | 24,0 | 410 | ||
0206024271000 | 206-24x27 | 193 | 32,6 | 36,6 | 24,0 | 445 |
